S890W Ελεγκτής PC + Rack CNC

The S890 W is the flagship PC + Rack CNC for high-end press brake automation. Equipped with a 32-inch Full HD multitouch display, support for 4 axes (expandable up to 256), and 32 digital inputs and outputs, it delivers maximum visualization, processing power, and flexibility for the most demanding bending applications.

SKU S890WCNC Cntrl-891 Κατηγορία Ελεγκτές Tags cnc controller, control units, Controllers Share

Buy Now

Λεπτομέρειες
Τεχνικά Χαρακτηριστικά

The S890 W represents the top model of the VIS-800 CNC series. Its large 32-inch Full HD touchscreen provides exceptional visibility for machine control, 2D/3D graphics, and complex bending operations, helping operators work faster and more efficiently.

Built for advanced hydraulic, hybrid, and electric press brakes, the S890 W supports 4 control axes as standard with expansion up to 256 axes, making it suitable for highly customized and automated production systems. Combining industrial-grade hardware, bundled CNC software, and Industry 4.0 connectivity, it offers outstanding performance, reliability, and scalability for modern manufacturing environments.

Διαμόρφωση	PC + Rack CNC
Οθόνη	32" TFT LCD
Ανάλυση	Full HD 1920 × 1080 (Wide Screen)
Οθόνη Αφής	PCAP 4 mm Cover Glass, 10 Touch Points, Optical Bonding, Aluminium Frame
CPU	Intel i5-6500 Quad Core 3.2 GHz (PC) + VIA Eden X1 1.06 GHz (Rack)
ΕΜΒΟΛΟ	8 GB DDR4 (PC) + 1 GB (Rack)
Αποθήκευση	256 GB mSATA SSD (PC) + 512 MB (Rack)
Μέγιστος Αριθμός Αξόνων	4 Axes (up to 256 as an option)
Ψηφιακές Είσοδοι/Έξοδοι	32 Inputs / 32 Outputs
